Part No. | Power switching | MODE | VDD | VOUT | IQ | FOSC | Eff. | Max. Duty Cycle | Accu. | IOUT | Package | Application |
BL8028 | Built-in MOSFET Synchronous | PWM/PFM | 2.6~5.5V | ADJ~V | 80μA | 2MHz | 0.97 | 1 | ±2% | 1500mA | DFN2x2-6, SOT23-5 | MID, TV, PON, STB |
BL8032 | Built-in MOSFET Synchronous | PWM/PFM | 4.2~18V | ADJ~V | 0.5mA | 500KHz | 0.96 | 0.92 | ±2% | 2000mA | SOT23-6 | STB, PON, TV |
BL8032H | Built-in MOSFET Synchronous | PWM/PFM | 4.2~18V | ADJ~V | 0.5mA | 1000KHz | 0.96 | 0.92 | ±2% | 2000mA | SOT23-6 | TV, STB, PON |
BL8032S | Built-in MOSFET Synchronous | PWM/PFM | 4.5~16V | ADJ~V | 0.5mA | 500KHz | 0.96 | 0.95 | ±2% | 2000mA | SOT23-6 | PON, STB, TV |
BL8033 | Built-in MOSFET Synchronous | PWM/PFM | 4.2~16V | ADJ~V | 0.5mA | 500KHz | 0.96 | 0.92 | ±2% | 3000mA | SOT23-6 | TV, STB, PON |
BL8034 | Built-in MOSFET Synchronous | PWM/PFM | 4.2~16V | ADJ~V | 0.5mA | 500KHz | 0.95 | 0.92 | ±2% | 4000mA | ESOP-8L | PON, STB, TV |
BL8035 | Built-in MOSFET Synchronous | PWM | 4.2~18V | ADJ~V | 0.5mA | 500KHz | 0.96 | 0.92 | ±2% | 2000mA | SOT23-6 | SSD |
BL9309 | Built-in MOSFET Synchronous | PWM/PFM | 2.5~5.5V | ADJ~V | 50μA | 1.3MHz | 0.97 | % | ±2.5% | 2000mA | SOT23-6, SOT23-5 | PON, STB, MID, TV |
BL9315 | Built-in MOSFET Synchronous | PWM/PFM | 2.6~5.5V | ADJ~V | 50μA | 1.4MHz | 0.97 | % | ±2.5% | 3000mA | ESOP8 | TV, STB |
BL9342 | Built-in MOSFET | PWM/PFM | 4.5~40V | ADJ~V | 0.2mA | 1.8MHz | 0.95 | 0.9 | ±2% | 0.6A | SOT23-6 | 电表, 车载, 载波模块 |
BL9366 | Built-in MOSFET | PWM/PFM | 4.5~60V | ADJ~V | 0.73mA | 480KHz | 0.95 | 0.9 | ±2% | 0.5A | SOT23-6 | 电表, 车载, 载波模块 |
